Mud Cat E-Series Electric Auger Dredges combines advanced remote-control technology with a quieter, zero-emission solution.
These dredges allow operators to manage dredging operations from a safe distance for environmentally sensitive areas or waterways with hazardous and potential toxic sludge like wastewater treatment plants, mining tailings dams, and industrial ponds.
Mud Cat’s unmanned electric dredges are built for long-term performance and precise sediment removal while reducing labour requirements. With features like the optional automation package, operators can program the dredge for consistent, hands-free operation, optimising productivity.
Remote operation to manage dredging activities from a safe, remote location with precise control, enhancing safety and efficiency.
The Microdredger has its own purpose built trailer which can be towed by a standard 4×4 and is easily launched into sensitive environmental areas.
The hydraulic tilting trailer allows the dredge to be launched and retrieved in areas inaccessible to a crane.
All E-Series dredges are equipped with variable frequency drives for managing flow. These systems also have a direct hydraulic drive for the slurry pump to prevent shaft failures.
Electric-powered systems reduce mechanical wear, and need for ongoing servicing, lowering maintenance demands and servicing costs.
| MODEL | Pipeline Diameter- Inches (mm) | Dredging Depth - Feet (m) | Installed HP (kW) | Average Flow Rate (gpm & m3/hour) | Head - Ft. (M) [@ Flow Rate] | Cutterheads | Propulsion | Portability (Road / Ocean) |
|---|---|---|---|---|---|---|---|---|
| MC 20E | 6 in (152 mm) | 14 ft (4.3m) | 20 HP (15 kW) |
600 gpm (136m3/hr) | 60 (18.30) | EnviroMaster Auger | Cable Drive | 1 truck / 40 ft container |
| MC 40E | 6 in (152 mm) | 14 ft (4.3m) | 40 HP (30 kW) |
900 gpm (204m3/hr) | 50 (15.25) | EnviroMaster Auger | Cable Drive | 1 truck / 40 ft container |
| MC 50E | 6 in (152 mm) | 17 ft (5.2m) | 50 HP (37 kW) |
1200 gpm (272m3/hr) | 60 (18.30) | EnviroMaster Auger | Cable Drive | 1 truck / 40 ft container |
| MC 100E | 10 in (254 mm) | 17 ft (5.2m) | 100 HP (76 kW) |
3,000 gpm (680m3/hr) | 60 (18.30) | EnviroMaster Auger | Cable Drive | 1 truck / flat rack |
APEX Envirocare supplied Aqua Barriers to dewater an environmentally sensitive area along the Swan River for road construction.
Our approach involved specialist dredge equipment with advanced features designed to handle challenging WWTP conditions.
